ZS1216C

€33,720.00 Z vključenim DDV

Kategorija:

Opis

Gosenične škarjaste dvižne ploščadi strankam ponujajo nove možnosti za delo na višini na neravnem in nestabilnem terenu.

Work Height 13.8m 45ft3in
A Platform Height-Elevated 11.8m 38ft9in
B Platform Height- -Stowed 1.62m 5ft4in
C Platform Length 2.3m 7ft7in
D Platform Width 1.12m 3ft8in
Platform Extension 0.91m 2ft12in
E Overall Height (Rails Up) 2.76m 9ft1in
Overall Height (Rails Down) 2.23m 7ft4in
F Overall Length 2.75m 9ft
G Overall Width 1.6m 5ft3in
H Ground Clearance 0.15m 6in
Performance
Platform Capacity 350kg 770lb
Capacity on Deck Extension 113kg 249lb
Max. Number of Workers 2 2
Drive Speed (Stowed) 2km/h 1.25mph
Drive Speed (Raised) 0km/h 0mph
Turning Radius 0m 0in
Drive Motor 48V/2×4KW 48V/2×4KW
Up/Down Time 62s/42s 62s/42s
Gradeability 30%(17°) 30%(17°)
Max. Working Slope (Lateral/Vertical) 2°/3° 2°/3°
Drive Rear Wheels Rear Wheels
Brake Rear Wheels Rear Wheels
Power
Battery 8×6V/240Ah 8×6V/240Ah
Charger 48V/35A 48V/35A
Weight
Gross 3750kg 8270lb
